used infrared dryer
• Working width: 700 mm
• 1 x short-wave IR radiation module with 27 kW consisting of 3 x 3 short-wave IR radiators with 3 kW each
V2A rod mesh conveyor belt
• Additional cooling bridges over the outlet (height adjustable)
• IR bulb unit is height adjustable from 70 - 120 mm
• Transport speed 0.25 - 2.5 m/min
• Heavy duty casters with brakes for easy IR dryer reorganization
• Connection voltage 400 V / 50 Hz, 3~/N/PE
• Connected load approx. 28 kW
• Exhaust air volume 37 m³/min (2,220 m³/h)
• Operation via button / potentiometer on the front panel
• LOGO compact controller with text display
• Bulb box can be pulled out to replace the emitters
